BIG.SEVEN 60

Regular price $999.00 Save $-999.00
BIG.SEVEN 60
BIG.SEVEN 60



THIS IS WHAT WE DO

Our classic hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we were able to gain in 48 years of bike production and manufacturing. The BIG.NINE and BIG.SEVEN range symbolises the symbiosis between modern frame technology, attention to detail and craftsmanship 'Made in Taiwan'.

MULTIPLE FRAME OPTIONS

Besides offering the BIG.NINE in a full carbon version, we also have BIG.NINE LITE and BIG.NINE/ SEVEN TFS aluminium frames in our range. While the LITE features the same race-proven geometry as the carbon models, the TFS bikes offer a more relaxed geometry, through a shorter top tube and a higher head tube, resulting in a more upright riding position and enhanced trail visibility. The TFS frames feature internal cable routing (except the BIG.NINE/BIG.SEVEN 15), smooth welding, tapered head tube, inboard disc mounts, and mounts for fenders, rear rack and kickstand.

01. FRAME BIG.SEVEN TFS III; MAT aluminium; 27.5 WHS; 135x9 AST; BSA BBR
02. SIZES XS-S-M-L
03. FORK Rock Shox Judy TK; Coil; 100 STR Lockout; 42mm fork offset
04. GEARS 2x 9
05. CRANKSET Shimano MT101-2; 36-22 teeth
06. CRANK LENGTH 170 mm-S, 175 mm-M up
07. BOTTOM BRACKET Shimano BB-UN100
08. CASSETTE Shimano CS-HG200; 11-32 ATC; 9 Speed
09. CHAIN KMC M99
10. CHAINGUARD -
11. FRONT DERAILLEUR Shimano M2020-TS
12. REAR DERAILLEUR Shimano RD-M370
13. SHIFTER-FRONT Shimano ST-EF505
14. SHIFTER-REAR Shimano ST-EF505
15. BRAKES Shimano ST-EF505; BR-MT200 brake caliper
16. ROTOR-FRONT Shimano RT10; 160 mm
17. ROTOR-REAR Shimano RT10; 160 mm
18. HANDLEBAR MERIDA CC; MAT aluminium; 690 Wide; 15 Rise
19. STEM MERIDA CC; MAT aluminium; 31.8 Diameter; 6 Angle
20. STEM LENGTH 70 mm-XS/S, 80 mm-M, 90 mm-L
21. HEAD SET MERIDA M2345
22. SEAT POST MERIDA CC; MAT aluminium; 30.9 Diameter; 15 Setback
23. SADDLE MERIDA Sport comfort
24. HUB-FRONT Shimano TX505; 100x9 WHF; 32 Spokes; Centerlock
25. HUB-REAR Shimano TX505; 135x9 WHR; 32 Spokes; Centerlock
26. AXLE-REAR -
27. SPOKES Black steel
28. RIMS MERIDA CC; 17 IWR; MAT aluminium
29. TYRES MERIDA K1080; 27.5x2.2"; wire
30. PEDALS Plastic VPE-891
