Shimano's EP8 motor offers a perfectly balanced power delivery with up to 85 Nm and has further improved on size, weight, noise and motor drag. The new 630 Wh battery is perfectly integrated into the hydroformed down tube and delivers an impressive range for even longer detours home.
The eBIG.TOUR EQ is rolling on 29er wheels which have fantastic ‘rolling over obstacles’ behaviour. As standard, it comes equipped with 2.2" wide tyres which offer plenty of grip and comfort. If no fenders are fitted, the tyres can go up to 2.35" improving the off-road riding characteristics even further.
The eBIG.TOUR EQ frame offers the possibility to fit a water bottle or further accessories like a lock or pump in two different positions. One is on the top of the down tube, while a second is below the top tube. This gives the rider, besides the possibility to mount bottle cages, the option to mount for example a folding-lock or pump bracket.
The system weight of a bike is the combined weight of bike, rider and additional luggage. The allowed system weight is 140 kg. As an e-bike is already heavier than a regular bike, and as it also makes it easier to transport larger amounts of luggage, it is imperative to certify a higher overall system weight. All MERIDA e-bikes, as well as all used componentry, go through a rigorous and e-bike specific testing schedule which mimics the higher forces and strains to guarantee the rider the highest level of safety.
100 mm up front offers lots of comfort while having plenty of reserves when you choose a more ‘off-road’ route home. Ultimately e-MTBs encourage the rider to go ‘off the beaten track’ whenever possible.
01. FRAME |
eBIG.TOUR LITE III; MAT aluminium; 29" WHS; 148x12 AST; intube; max. 630 Wh |
02. SIZES |
S-M-L-XL |
03. FORK |
Suntour XCR34 LOR DS; Air Boost; 100mm; Tapered; 51mm fork offset |
04. DRIVE UNIT |
Shimano EP8; 85Nm |
05. BATTERY |
Shimano E8036; 630Wh |
06. BATTERY CHARGER |
Shimano EC-E6002; 2A |
07. DISPLAY |
Shimano SC-E5003 |
08. REAR DERAILLEUR |
Shimano Deore RDM5100 11 |
09. SHIFTERS |
Shimano Deore M5100 11 |
10. BRAKE - FRONT |
Shimano MT402-3A; 2 piston |
11. BRAKE - REAR |
Shimano MT402-3A; 2 piston |
12. ROTOR - FRONT |
Shimano RT30; 180 mm |
13. ROTOR - REAR |
Shimano RTEM300; 180 mm |
14. CHAINWHEEL |
Shimano CRE70-B; 34 ATC |
15. CRANK/SIZE |
Shimano FCEM600; 165 mm for all sizes |
16. CHAIN |
HG601-11 |
17. CASSETTE |
Shimano M5100; 11-51 ATC; 11 GER |
18. PEDALS |
VP; VPE-537 |
19. HANDLEBAR |
MERIDA Expert CC; MAT aluminium; 720 WHB; 10 RHB |
20. HANDLEBAR STEM |
MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable |
21. STEM LENGTH |
90 mm all sizes |
22. SEAT POST |
MERIDA EXPERT CC; MAT aluminium; 34.9 DSP; 0 SSB |
23. SADDLE |
MERIDA Comp CC; V-mount |
24. HUB - FRONT |
Shimano MT400-B; 110x15 WHF; 32 SPH; Centerlock |
25. HUB - REAR |
Shimano MT400-B; 148x12 WHR; 36 SPH; Centerlock |
26. AXLE - REAR |
MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
27. RIMS |
MERIDA COMP CC; 20 IWR; MAT aluminium |
28. TYRES |
KENDA Booster; 29x2.2"; wire |
29. FENDERS |
Sunnywheel SW-FA311-65A/ SW-FA311-65E1 |
30. KICKSTAND |
CL-KA98, 29" |
31. LIGHT - FRONT |
E-BIKE POWER STVZO E115, X-Lock stem mount |
32. LIGHT - REAR |
Spanninga Commuter GLOW XE |
