Frame

Level 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 170mm travel, Forward Geometry, internal removable battery with integrated alloy cover, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Rear shock

Öhlins TTX22M 225x75mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, spring preload. Trunnion top mount, 25x10mm bottom bushings

Shock settings

C10 compression, R35 rebound. Spring rate: S size 251 lbs, M size 297 lbs, L size 343 lbs, XL size 411 lbs

Fork

Öhlins RXF 38 29, 180mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Stem

Onoff Krypton FG 30mm, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff Krypton Carbon 1.0, rise: 25mm, width: 780mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips

Onoff Desert, 1lock-on, 135mm, sizes: S/M L/XL

Seatpost

Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm

Saddle

SDG BEL-AIR 3.0, EVA foam, Alloy rails

Front brake

Sram Code RSC, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Rear brake

Sram Code RSC, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Brake lever

Sram Code RSC, SwingLink and lever pivot bearings, tools-free reach and contact point adjust

Rims

e*thirteen E*Spec Plus, IW30 Hookless, 6069 Welded Aluminum 30mm internal width, tubeless ready, 28F / 32R spokes

Spokes

e*thirteen custom J-bend, triple-butted alloy, alloy nipples, nipple washers

Front hub

e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts

Rear hub

e*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts

Front tire

Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead

Rear tire

Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead

Crankset

E.13 E*Spec Plus ebike, 165mm

Rings

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Chain

Sram GX Eagle, 12s, Powerlock

Rear derrailleur

Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Shift levers

Sram Trigger GX Eagle, 12s, X-Actuation 1:1, single click

Casette

Sram PG-1230, 11-50T, 12s

Derailleur hanger

Mondraker M068

Weight

25.5 kg

Display

Bosch Kiox

Motor

Bosch Performance Line CX Cruise (25Km/h) GEN4

Battery

Bosch Powertube 625Wh


Crafty Stealth Air full Carbon, Zero suspension system optimized for e-Bike, Forward, Geometry, 150mm travel, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, monobloc top link, HHG internal routing, MAX sealed bearings , 17mm oversized axles, integrated dropout speed sensor, plastic engine guard

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Shock absorber

Fox Float DPS Performance, 205x65mm. Adjustments: Lever with 3 compression positions, low speed rebound and air preload. Trunnion top anchor, bottom 25x10mm with bushings

Damper adjustment

Compression 'medium', rebound 'medium', volume spacer 0.4

Fork

Fox 36 29 Float FIT GRIP EVOL Performance, 160mm, e-bike optimized, tapered head tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3-position micro-adjust compression, low-speed rebound, and air preload

Direction

1-1 / 2 "custom acros, 40x52x7 angular contact bearings, internal cable routing

Power

Onoff Krypton FG 30mm, forged 6061 alloy, 31.8mm bore

Handlebar

Onoff Krypton 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm bore

Cuffs

Onoff Desert, 1lock-on, 135mm, sizes: S / ML / XL

Shank

Onoff Internal dropper sleeve, diameter 31.6mm, size S: 387x125mm, size M: 425x150mm, sizes L / XL: 465x170mm

Saddle

Fizik Antares R7

Front brake

Sram G2 RSC, 4-piston caliper, 200mm one-piece Centerline discs, 6-bolt IS, organic steel-backed pads

Back brake

Sram G2 RSC, 4-piston caliper, 200mm one-piece Centerline discs, 6-bolt IS, organic steel-backed pads

Brake levers

Sram G2 RSC, lever and SwingLink bearings, lever reach adjustments and tool-free pad contact

Rims

DT Swiss H1900 Spline 29, 30mm inner width, alloy, tubeless ready, 28h

Radios

DT Hybrid SP, direct pull

Front hub

DT 370, Boost 15x110mm, IS 6 bolts

Rear hub

DT 370, Boost 12x148mm, 3 Pawl system, IS 6 bolt

Front tire

Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Rear tire

Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Connecting rods

E.13 E * Spec Plus ebike, 165mm

Dishes

Sram X-Sync 2 Eagle 34 tooth, alloy, narrow-wide, 104 BCD

Chain

Sram NX Eagle, 12v, Powerlock

Shift - rear

Sram GX Eagle, Type 3 lock-out, 1x12v, X-Actuation 1: 1

Controls - change buttons

Sram Trigger NX Eagle, 12v, X-Actuation 1: 1, single click

Pinions

Sram XG-1230, 11-50 teeth, 12v

Derailleur hanger

Mondraker M068

Weight without pedals

22.0 kg

Display

Bosch Kiox

Motor

Bosch Performance Line CX Cruise (25Km / h) GEN4

Battery

Bosch Powertube 625Wh


Crafty Stealth Evo 6061 alloy, Zero suspension system optimized for e-Bike, Forward Geometry, 150mm travel, removable internal battery with aluminum protector, Boost 12x148mm rear axle, tapered head tube, monobloc top link, HHG internal routing, ball bearings MAX sealed, 17mm oversized axles, integrated dropout speed sensor, plastic engine guard

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Shock absorber

Fox Float DPX2 LV EVOL Performance, 205x65mm. Adjustments: Lever with 3 compression positions, low speed rebound and air preload. Trunnion top anchor, bottom 25x10mm with bushings

Damper adjustment

CEC001 compression, 'medium' rebound, 0.2 volume spacer

Fork

Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike optimized, tapered head tube, Boost 15x110mm axle, 44mm offset. Settings: 3-position micro-adjust compression, low-speed rebound, and air preload

Direction

Onoff Saturn tapered 1-1 / 8 "to 1-1 / 2", ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Power

Onoff Sulfur FG 30mm 0º, forged 6061 alloy, 31.8mm bore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm bore

Cuffs

Onoff Desert, 1lock-on, 135mm, sizes: S / ML / XL

Shank

Onoff Internal dropper sleeve, diameter 31.6mm, size S: 387x125mm, size M: 425x150mm, sizes L / XL: 465x170mm

Saddle

SDG BEL-AIR 3.0, EVA foam, steel rails

Front brake

Sram G2 R, 4-piston caliper, IS 6-bolt one-piece Centerline 200mm rotor, organic steel mount pads

Back brake

Sram G2 R, 4-piston caliper, IS 6-bolt one-piece Centerline 200mm rotor, organic steel mount pads

Brake levers

Sram G2 R, tool-free reach adjustment

Rims

DT Swiss H1900 Spline 29, 30mm inner width, alloy, tubeless ready, 28h

Radios

DT Hybrid SP, direct pull

Front hub

DT 370, Boost 15x110mm, IS 6 bolts

Rear hub

DT 370, Boost 12x148mm, triple ratchet system, IS 6 bolts

Front tire

Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Rear tire

Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Connecting rods

Race Face Aeffect ebike, 165mm

Dishes

Sram X-Sync 2 Eagle 34 tooth, steel, narrow-wide, 104 BCD

Chain

Sram SX Eagle, 12v, Powerlock

Shift - rear

Sram GX Eagle, Type 3 lock-out, 1x12v, X-Actuation 1: 1

Controls - change buttons

Sram Trigger NX Eagle, 12v, X-Actuation 1: 1, single click

Pinions

Sram PG-1210, 11-50 teeth, 12v

Derailleur hanger

Mondraker M068

Weight without pedals

24.9 kg

Display

Bosch Kiox

Motor

Bosch Performance Line CX Cruise (25Km / h) GEN4

Battery

Bosch Powertube 625Wh


Dusk Stealth Evo Aluminum 6061, Zero suspension system optimized for e-Bike, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, monobloc top link, HHG internal routing, MAX sealed bearings, 17mm oversized axles, speed sensor integrated in the toe box. * Optional external battery

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Shock absorber

Fox Float DPS LV EVOL Performance, 205x65mm. Settings: 3-position compression per lever, low speed rebound and air preload. Trunnion top anchor, bottom 25x10mm with bushings

Damper adjustment

Compression 'medium', rebound 'medium', volume spacer 0.4

Fork

Fox 36 29 Float FIT4 EVOL Factory Kashima, 160mm, e-bike optimized, tapered head tube, 15x110mm Boost axle, 44mm offset, 68mm OD crown. Settings: 3-position micro-adjust compression, low-speed rebound, and air preload

Direction

Onoff Saturn tapered 1-1 / 8 "to 1-1 / 2", ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Power

Onoff Sulfur FG 30mm 0º, forged 6061 alloy, 31.8mm bore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm bore

Cuffs

Onoff Twin, 1lock-on, 135mm

Shank

Onoff Internal dropper sleeve, diameter 31.6mm, size S: 387x125mm, size M: 425x150mm, sizes L / XL: 465x170mm

Saddle

Mondraker e-MTB custom design

Front brake

Shimano M6120, 4-piston caliper, RT66 203mm IS 6-bolt rotor, resin pads

Back brake

Shimano M6120, 4-piston caliper, RT66 203mm IS 6-bolt rotor, resin pads

Brake levers

Shimano M6100, servo wave, aluminum lever, reach adjustment with tool

Rims

DT Swiss H1900 Spline 29, 30mm inner width, alloy, tubeless ready, 28h

Radios

DT Hybrid SP, direct pull

Front hub

DT 370, Boost 15x110mm, IS 6 bolts

Rear hub

DT 370, Boost 12x148mm, triple ratchet system, IS 6 bolts

Front tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO, 60TPI, folding

Rear tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO, 60TPI, folding

Connecting rods

Shimano STEPS EM600, 165mm

Dishes

Shimano E8000 34 tooth, steel, 104 BCD

Chain

Shimano Deore M6100, 12v, Quick-link

Shift - rear

Shimano XT M8100, SGS, Shadow +, 12v

Controls - change buttons

Shimano Deore M6100, Rapid Fire Plus, 12s

Pinions

Shimano Deore M6100, 10-51 teeth Hyperglide +, 12s

Derailleur hanger

Mondraker M068

Others

* Optional external battery: Simplo 360Wh

Weight without pedals

23.0 kg

Display

Shimano STEPS E7000

Motor

Shimano STEPS EP800

Battery

Simplo internal 630Wh


Dusk Stealth Evo Aluminum 6061, Zero suspension system optimized for e-Bike, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, monobloc top link, HHG internal routing, MAX sealed bearings, 17mm oversized axles, speed sensor integrated in the toe box. * Optional external battery

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Shock absorber

Fox Float DPS LV EVOL Performance, 205x65mm. Settings: 3-position compression per lever, low speed rebound and air preload. Trunnion top anchor, bottom 25x10mm with bushings

Damper adjustment

Compression 'medium', rebound 'medium', volume spacer 0.4

Fork

Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, e-bike optimized, tapered head tube, 15x110mm Boost axle, 44mm offset. Adjustments: compression to lock, low speed rebound and air preload

Direction

Onoff Saturn tapered 1-1 / 8 "to 1-1 / 2", ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Power

Onoff Sulfur FG 30mm 0º, forged 6061 alloy, 31.8mm bore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm bore

Cuffs

Onoff Twin, 1lock-on, 135mm

Shank

Onoff Internal dropper sleeve, diameter 31.6mm, size S: 387x125mm, size M: 425x150mm, sizes L / XL: 465x170mm

Saddle

Mondraker e-MTB custom design

Front brake

Shimano MT420, 4-piston caliper, RT66 203mm IS 6-bolt rotor, resin pads

Back brake

Shimano MT420, 4-piston caliper, RT66 203mm IS 6-bolt rotor, resin pads

Brake levers

Shimano M4100, servo wave, aluminum lever, reach adjustment with tool

Rims

MDK-HP1 29, 30mm internal width, tubeless ready, 32h

Radios

CN stainless steel round section

Front hub

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolt

Rear hub

Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts

Front tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO, 60TPI, folding

Rear tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO, 60TPI, folding

Connecting rods

Shimano STEPS EM600, 165mm

Dishes

Shimano E8000 34 tooth, steel, 104 BCD

Chain

Shimano Deore M6100, 12v, Quick-link

Shift - rear

Shimano Deore M6100, SGS, Shadow +, 12v

Controls - change buttons

Shimano Deore M6100, Rapid Fire Plus, 12s

Pinions

Shimano Deore M6100, 10-51 teeth Hyperglide +, 12s

Derailleur hanger

Mondraker M068

Others

* Optional external battery: Simplo 360Wh

Weight without pedals

23.6 kg

Display

Shimano STEPS E7000

Motor

Shimano STEPS EP800

Battery

Simplo internal 630Wh


Full Carbon SuperFoxy 29 Stealth Air frame, Zero suspension system, 160mm travel, Forward Geometry, monobloc carbon top link, 12x157mm SuperBoost rear axle, tapered head tube, 73mm BSA threaded bottom bracket, 1x drivetrain design, internal routing HHG wiring harness, Enduro MAX sealed bearings, shock mudguard, ISCG 05 mount, frame protectors. * Geometry change kit included

Sizes

S: 380mm / M: 420mm / L: 470mm / XL: 510mm

Shock absorber

Öhlins TTX Air 205X62.5 mm, Settings: high speed compression lever with rise mode, low speed compression, rebound, air preload, top link, 22.2X10mm bottom bushings

Damper adjustment

C20 compression, R35 Rebound

Fork

Fox 38 29 Float FIT GRIP EVOL Performance, 170mm, tapered head tube, Boost 15x110mm axle, 44mm offset. Adjustments: 3 positions with micro adjustment of compression, low speed rebound and air preload

Direction

Onoff Titan tapered 1-1 / 8 "to 1-1 / 2", ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º

Fork remote control

-

Power

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm diameter

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm bore

Cuffs

Onoff Desert, 1lock-on, 135mm, sizes: S / ML / XL

Shank

Onoff Internal Guided Pija, diameter 31.6mm, size S: 337x100mm, size M: 387x125mm, size L: 425x150mm, size XL: 465x170mm

Saddle

SDG BEL-AIR 3.0, LPU foam, steel rails

Front brake

Sram Code R, 4-piston caliper, 200mm one-piece Centerline discs, 6-bolt IS, sintered pads with steel mount

Back brake

Sram Code R, 4-piston caliper, 200mm one-piece Centerline discs, 6-bolt IS, sintered pads with steel mount

Brake levers

Sram Code R, tool-free adjustable lever reach

Rims

DT Swiss E1900 Spline 29, 30mm inner width, alloy, tubeless ready, 28h

Radios

DT Champion, direct shot

Front hub

DT 370, Boost 15x110mm, IS 6 bolts

Rear hub

DT 370, SuperBoost 12x157mm, triple ratchet system, IS 6 bolt, XD freehub

Front tire

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Rear tire

Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Connecting rods

Truvativ Descendant 7K Eagle, SuperBoost, DUB axle, Direct mount chainring, sizes S / M: 170mm, sizes L / XL: 175mm

Dishes

32 tooth, CNC aluminum, X-SYNC 2

Bottom bracket

Sram DUB BSA, sealed bearings, 73mm threaded

Chain

Sram NX Eagle, 12v, Powerlock

Shift - rear

Sram GX Eagle, Type 3, lock-out, 1x12v, X-Actuation 1: 1

Controls - change buttons

Sram Trigger GX Eagle, 12v, X-Actuation 1: 1

Pinions

Sram XG-1275, 10-52 teeth, 12v

Derailleur hanger

Mondraker M071

Others

* Optional geometry kit: 0º cups and chainstay length adapter for 450mm

Weight without pedals

14.9 kg


Aluminum 6061 SuperFoxy 29 Stealth Evo, hydroformed tubing, Zero suspension system, monobloc upper link, SuperBoost 12x157mm rear axle, tapered head tube, 73mm BSA threaded bottom bracket, 1x drivetrain design, internally routed seatpost, MAX sealed bearings, ISCG 05

Sizes

S: 380mm / M: 420mm / L: 470mm / XL: 510mm

Shock absorber

Fox Float DPX2 LV EVOL Performance, 205x65mm. Settings: 3 compression settings, low speed rebound and air preload. Trunnion top anchor, bottom 22.2x10mm with bushings

Damper adjustment

CEC001 compression, medium rebound, 0.2 volume spacers

Fork

RockShox Zeb RC 29, 170mm, Charger, DebonAir, tapered head tube, 15x110mm Boost axle, 38mm alloy stanchions, 44mm offset. Adjustments: low speed compression to lock, rebound and air preload

Direction

Onoff Saturn tapered 1-1 / 8 "to 1-1 / 2", ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Fork remote control

-

Power

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm diameter

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm bore

Cuffs

Onoff Twin, 1lock-on, 135mm

Shank

Onoff Internal Guided Pija, diameter 31.6mm, size S: 337x100mm, size M: 387x125mm, size L: 425x150mm, size XL: 465x170mm

Saddle

SDG BEL-AIR 3.0, LPU foam, steel rails

Front brake

Sram G2 R, 4-piston caliper, 200mm one-piece Centerline discs, 6-bolt IS, organic steel-backed pads

Back brake

Sram G2 R, 4-piston caliper, 200mm one-piece Centerline discs, 6-bolt IS, organic steel-backed pads

Brake levers

Sram G2 R, tool-free adjustable lever reach

Rims

MDK-EP1 29 TLR ASY, asymmetric rim, 30mm internal width, tubeless ready, 32 spokes

Radios

CN stainless steel round section

Front hub

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolt

Rear hub

Formula DC157, SuperBoost 12x157mm, sealed bearings, IS 6 bolt

Front tire

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Rear tire

Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Connecting rods

Truvativ Descendant 7K Eagle, SuperBoost, DUB axle, Direct mount chainring, sizes S / M: 170mm, sizes L / XL: 175mm

Dishes

32 tooth, CNC aluminum, X-SYNC 2

Bottom bracket

Sram DUB BSA, sealed bearings, 73mm threaded

Chain

Sram SX Eagle, 12v, Powerlock

Shift - rear

Sram SX Eagle, Type 3, lockout, long cage, 1x12v, X-actuation 1: 1

Controls - change buttons

Sram Trigger SX Eagle, 12v, X-Actuation 1: 1

Pinions

Sram PG-1210, 11-50 teeth, 12v

Derailleur hanger

Mondraker M068

Weight without pedals

15.8 kg


Foxy 29 6061 Stealth Evo Alloy, hydroformed tubing, Zero suspension system, 150mm travel, Forward Geometry, monobloc top link, Boost 12x148 rear axle, tapered head tube, 73mm BSA threaded bottom bracket, 1x drivetrain design, guided inner seatpost, MAX sealed bearings, ISCG 05 mount

Sizes

S: 380mm / M: 420mm / L: 470mm / XL: 510mm

Shock absorber

Fox Float DPS LV EVOL Performance, 205x62.5mm. Settings: rebound, 3 compression positions (Open / Mid / Lock), air preload. Trunnion top anchor, bottom 22.2x10mm with bushings

Damper adjustment

Compression 'light', rebound 'extralight', 0.6 volume spacer

Fork

Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, comnified head tube, Boost 15x110mm axle, 44mm offset. Adjustments: compression, low speed rebound and air preload

Direction

Onoff Saturn tapered 1-1 / 8 "to 1-1 / 2", ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Fork remote control

-

Power

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm diameter

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm bore

Cuffs

Onoff Twin, 1lock-on, 135mm

Shank

Onoff Internal Guided Pija, diameter 31.6mm, size S: 337x100mm, size M: 387x125mm, size L: 425x150mm, size XL: 465x170mm

Saddle

SDG BEL-AIR 3.0, LPU foam, steel rails

Front brake

Sram G2 R, 4-piston caliper, 200mm one-piece Centerline discs, 6-bolt IS, organic steel-backed pads

Back brake

Sram G2 R, 4-piston caliper, 180mm one-piece Centerline discs, 6-bolt IS, organic steel-backed pads

Brake levers

Sram G2 R, tool-free lever reach adjustment

Rims

MDK-EP1 29 TLR ASY, asymmetric, 30mm internal width, tubeless ready, 32 spokes

Radios

CN stainless steel round section

Front hub

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolt

Rear hub

Formula MST148S-4SB, Boost 12x148mm, sealed bearings, IS 6 bolt

Front tire

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO +, 120TPI, foldable

Rear tire

Maxxis Aggressor 29x2.3, tubeless ready, dual compound, EXO, 60TPI, folding

Connecting rods

Sram SX Eagle, Boost, DUB axle, Direct Mount chainring, sizes S / M: 170mm, sizes L / XL: 175mm

Dishes

32 tooth, steel, X-Sync 2

Bottom bracket

Sram DUB BSA, sealed bearings, 73mm threaded

Chain

Sram SX Eagle, 12v, Powerlock

Shift - rear

Sram SX Eagle, Type 3 lockout, long cage, 1x12v, X-actuation 1: 1

Controls - change buttons

Sram Trigger SX Eagle, 12v, X-Actuation 1: 1

Pinions

Sram PG-1210, 11-50 teeth, 12v

Derailleur hanger

Mondraker M068

Weight without pedals

15.5 kg


Level Aluminum 6061 Stealth Evo, Zero suspension system optimized for e-Bike, 170mm travel, Forward Geometry, removable internal battery with integrated aluminum protector, Boost 12x148mm rear axle, tapered head tube, monobloc top link, HHG internal routing, MAX sealed bearings, 17mm oversized axles, integrated dropout speed sensor, plastic motor guard

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Shock absorber

Öhlins TTX22M 225x75mm. Adjustments: High speed compression lever with 'climb' mode, low speed compression, rebound and spring preload. Trunnion top anchor, bottom 25x10mm with bushings

Damper adjustment

C10 compression, R35 rebound. Spring hardness: size S: 251 lbs, size M: 297 lbs, size L: 343 lbs, size XL: 411 lbs

Fork

Öhlins RXF 38 29, 180mm, TTX18 Twin Tube cartridge, tapered head tube, Boost 15x110mm axle, 44mm offset. Settings: High speed compression lever with 'climb' mode, low speed compression, rebound, air preload and 'ramp chamber'

Direction

Onoff Saturn tapered 1-1 / 8 "to 1-1 / 2", ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Power

Onoff Krypton FG 30mm, forged 6061 alloy, 31.8mm bore

Handlebar

Onoff Krypton Carbon 1.0, rise: 25mm, width: 780mm, 9th backsweep, 5th upsweep, 31.8mm diameter

Cuffs

Onoff Desert, 1lock-on, 135mm, sizes: S / ML / XL

Shank

Onoff Internal dropper sleeve, diameter 31.6mm, size S: 387x125mm, size M: 425x150mm, sizes L / XL: 465x170mm

Saddle

SDG BEL-AIR 3.0, EVA foam, aluminum rails

Front brake

Sram Code RSC, 4-piston caliper, IS 6-bolt one-piece 220mm Centerline rotor, sintered pads with steel mount

Back brake

Sram Code RSC, 4-piston caliper, IS 6-bolt one-piece Centerline 200mm rotor, sintered pads with steel mount

Brake levers

Sram Code RSC, lever and SwingLink bearings, tool-free lever reach and pad contact adjustments

Rims

e * thirteen E * Spec Plus, IW30 Hookless, 6069 alloy, 30mm internal width, tubeless ready, 28-spoke front / 32-spoke rear

Radios

e * thirteen custom J-bend, triple butted alloy, alloy nipples and washers

Front hub

e * thirteen Boost 15x110mm, triple sealed, machined aluminum, IS 6 bolt

Rear hub

e * thirteen Boost 12x147mm, triple sealed, machined aluminum, with 6 degree engagement, IS 6 bolts

Front tire

Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH shell, 60x2TPI, foldable

Rear tire

Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH shell, 60x2TPI, foldable

Connecting rods

E.13 E * Spec Plus ebike, 165mm

Dishes

Sram X-Sync 2 Eagle 34 tooth, steel, narrow-wide, 104 BCD

Chain

Sram GX Eagle, 12v, Powerlock

Shift - rear

Sram X01 Eagle, Type 3 locking, 1x12v, X-Actuation 1: 1

Controls - change buttons

Sram Trigger GX Eagle, 12v, X-Actuation 1: 1, single click

Pinions

Sram PG-1230, 11-50 teeth, 12V

Derailleur hanger

Mondraker M068

Weight without pedals

25.5 kg

Display

Bosch Kiox

Motor

Bosch Performance Line CX Cruise (25Km / h) GEN4

Battery

Bosch Powertube 625Wh
